SP-50C6-H medical hospital syringe infusion pump price

SP-50C6-H Medical Hospital Syringe Infusion Pump

Function :

KVO rate
Safety lock for PURGE/BOLUS
All brands of syringes are available
Preset occlusion detection pressure level
Preset Volume To Be Infused
Dual channel
RS232 interface
4500 history log
Standby function
Double CPU
Vehicle Power
Power indicator
Inquiry of total infused volume
Bolus release
Automatic syringe size detection
Safety lock for flow rate adjust

Technical parameters:

Syringe pump Parameter
Syringe Size	5ml, 10ml, 20ml, 30ml, 50ml ( optional: 1/2/3mL )
Flow Rate	0.0-150ml/h (0.1ml/h increment) 5ml syringe 0.0-300ml/h (0.1ml/h increment) 10ml syringe 0.0-600ml/h (0.1ml/h increment) 20ml syringe 0.0-900ml/h (0.1ml/h increment) 30ml syringe 0.0-1200ml/h (0.1ml/h increment,1ml/h increment if over 1000ml/h) 50ml syringe
Precision	≤±2%(mechanism≤±1%)
Inquiry of total volume	0.0ml-9999ml(0.1ml increment, 1ml increment if over 1000ml)
VTBI	0.0ml-9999ml(0.1ml increment, 1ml increment if over 1000ml)
Occlusion Value	High(H):800±200mmHg (106.7±26.7kPa) Centre(C):500±100mmHg (66.7±13.3kPa) Low(L):300±100mmHg (40.7±13.3kPa)
Alarm	Remind alarm,Occlusion alarm,Near empty alarm, Empty alarm, syringe barrel unlock alarm, syringe plunger disengage alarm, syringe flange disengage alarm, AC power failure, Low battery alarm, Battery empty alarm, VTBI finish reminder, infusion tube disconnect(option)
Power	AC:100V-240V±10%, 50Hz-60Hz±1Hz Built-in Battery:DC15V Ni-MH battery. Built-in battery can run for 10 hours at 5ml/h. (It can be replaced by lithium ion battery pack if necessary.) DC:DC15V,vehicle power
Running Environment	Temperature:+5℃-+40℃ Relative Humidity:20%-90% Atmosphere Pressure:860hPa-1060hPa
Transport And Storage Environment	Temperature:-20℃-+55℃ Relative Humidity:10%-93% Atmosphere Pressure:500hPa-1060hPa
Electric Safety Classification	Class I, CF type,Built-in battery,Continuous operation equipment
Water Proof Level	IPX4
Net Weight	2.2kg(include fastener)
Dimension	320mm(W)× 132mm(H)× 138mm(D)
Function
KVO rate Safety lock for PURGE/BOLUS All brands of syringes are available Preset occlusion detection pressure level Preset Volume To Be Infused Varied video and audio alarm RS232 interface 4500 history log	Standby function Safety lock for flow rate adjust Automatic syringe size detection Bolus release Inquiry of total infused volume Power indicator Vehicle Power Double CPU
Advanced Function
Adjust occlusion detection pressure Adjust KVO rate Preset maximum limit amount of single bolus Preset volume of alarm voice	Calibrate parameter of syringe Preset residual amount of solution Preset maximum value of flow rate Preset system time

KVO rate
Safety lock for PURGE/BOLUS
All brands of syringes are available
Preset occlusion detection pressure level
Preset Volume To Be Infused
Dual channel
RS232 interface
4500 history log
Standby function
Double CPU
Vehicle Power
Power indicator
Inquiry of total infused volume
Bolus release
Automatic syringe size detection
Safety lock for flow rate adjust

Technical parameters:

Syringe pump Parameter
Syringe Size	5ml, 10ml, 20ml, 30ml, 50ml ( optional: 1/2/3mL )
Flow Rate	0.0-150ml/h (0.1ml/h increment) 5ml syringe 0.0-300ml/h (0.1ml/h increment) 10ml syringe 0.0-600ml/h (0.1ml/h increment) 20ml syringe 0.0-900ml/h (0.1ml/h increment) 30ml syringe 0.0-1200ml/h (0.1ml/h increment,1ml/h increment if over 1000ml/h) 50ml syringe
Precision	≤±2%(mechanism≤±1%)
Inquiry of total volume	0.0ml-9999ml(0.1ml increment, 1ml increment if over 1000ml)
VTBI	0.0ml-9999ml(0.1ml increment, 1ml increment if over 1000ml)
Occlusion Value	High(H):800±200mmHg (106.7±26.7kPa) Centre(C):500±100mmHg (66.7±13.3kPa) Low(L):300±100mmHg (40.7±13.3kPa)
Alarm	Remind alarm,Occlusion alarm,Near empty alarm, Empty alarm, syringe barrel unlock alarm, syringe plunger disengage alarm, syringe flange disengage alarm, AC power failure, Low battery alarm, Battery empty alarm, VTBI finish reminder, infusion tube disconnect(option)
Power	AC:100V-240V±10%, 50Hz-60Hz±1Hz Built-in Battery:DC15V Ni-MH battery. Built-in battery can run for 10 hours at 5ml/h. (It can be replaced by lithium ion battery pack if necessary.) DC:DC15V,vehicle power
Running Environment	Temperature:+5℃-+40℃ Relative Humidity:20%-90% Atmosphere Pressure:860hPa-1060hPa
Transport And Storage Environment	Temperature:-20℃-+55℃ Relative Humidity:10%-93% Atmosphere Pressure:500hPa-1060hPa
Electric Safety Classification	Class I, CF type,Built-in battery,Continuous operation equipment
Water Proof Level	IPX4
Net Weight	2.2kg(include fastener)
Dimension	320mm(W)× 132mm(H)× 138mm(D)
Function
KVO rate Safety lock for PURGE/BOLUS All brands of syringes are available Preset occlusion detection pressure level Preset Volume To Be Infused Varied video and audio alarm RS232 interface 4500 history log	Standby function Safety lock for flow rate adjust Automatic syringe size detection Bolus release Inquiry of total infused volume Power indicator Vehicle Power Double CPU
Advanced Function
Adjust occlusion detection pressure Adjust KVO rate Preset maximum limit amount of single bolus Preset volume of alarm voice	Calibrate parameter of syringe Preset residual amount of solution Preset maximum value of flow rate Preset system time

1CE CERTIFICATE for Annecy machinery.jpg 1hospital bed.jpg

Packaging:

Generally, we pack our goods in noutral cardboard box or wooden box. If you have legally registered patent, we can pack the goods in your branded boxes

atter geting your authorization iatpers.

Shipping:

Generally, it will lake 7 1o 20 days affer receiving your advance payment

Te specifc delivery lime depano on te lams ind the quantiy of your order.

Sample Availability & Pollcy

We can supply the sample if we have reacy parts in stock, but the cuslomers have to pay the sample cbst and the courier cost.
